Door Control
Series A ZHUTAO.
High-performance structural glass entry solutions. The ZHUTAO Series A introduces the ultimate ecosystem for heavy monolithic and laminated glass panels (10mm to 19mm). Manufactured with structural-grade aluminum castings, thick SS304 covers, and heavy-duty inserts, it supports weights up to 150kg with complete safety alignment.
ZHUTAO Series A Door Controls
All-in-one commercial glass entry accessories and fittings
Engineering & Custom Finish
Configure internal structural castings to support custom spindles, special pivot heights, or tailored glass dimensions. Covers available in Mirror (PSS), Satin (SSS), PVD Gold, or Matte Black finishes.
OEM Mold Engineering
High-efficiency manufacturing pipelines for architectural hardware distributors. Support includes custom branding laser engraving, specialized limit plate setups, and eco-friendly non-asbestos gaskets.
Consolidated Logistics
Direct-from-factory volume supply chain options, global port consolidations, and standardized packaging tailored to protect heavy hardware consignments across long international transit routes.
Technical Resource Center
Acquire millimeter-precise dimensional schemas, glass cutout templates, and installation manuals for the entire ZHUTAO Door Control catalog.
Engineering Assets
Request DXF / DWG CAD Templates
Gain absolute precision for CNC glass cutting machinery. Contact our design office to receive detailed .dwg cut paths for the VM-10, VM-20, and lock cutouts.
Contact Project EngineeringCore Structural Component Specs
Select a core model below to review detailed CAD-standard layouts, glass machining cutout parameters, and compatibility specs extracted directly from the engineering files.
Select Hardware Component
BM-VM-10 Details
Technical Specifications
- Structure Core: Aluminum Castings / SS Inserts
- Maximum Load: Max Door Weight ≤ 100kg
- Door Width Spec: Max Door Width ≤ 1100mm
- Glass Thickness: 10mm - 12mm Tempered Glass
- Vibration Damping: Non-Asbestos Eco Gaskets
Full System Component Directory
Every accessory type from the ZHUTAO Series A portfolio. Crafted from solid stainless steel alloys, zinc casting cores, and pure brass cylinders.
1. Standard Patch Fittings
Bottom Patch Fitting
Secures directly over floor closer spindles. Supports dual-action structural glass pivots.
Top Patch Fitting
Integrated brass pivot pin socket. Compatible with top transom pivots or walkbeams.
Overpanel Patch
Anchor pivot connection designed for transom panel assemblies. Fitted with safety inserts.
Transom with Wall Bracket
Transom patch with horizontal projection plate for direct anchoring onto solid side masonry walls.
Sidelite Transom Fin Patch
Heavy-duty structural clamp supporting transom glass panels with integrated safety fin adapters.
Double Transom Fin Patch
T-junction structural connector linking double transoms and fin glass plates safely.
Sidelite Connector Fin Patch
Inline connector patch designed to bind adjacent sidelites and structural fin glass panels.
Sidelite 90° Corner Patch
90-degree corner patch connector (with short plate variant) linking top transoms to side panels.
2. Heavy-Duty & S.S. 304 Adjustable Range
15mm/19mm Bottom Patch
Extra-large core casting providing wider glass contact area for heavy 15-19mm monolithic systems.
15mm/19mm Top Patch
Heavy-duty top patch matching structural glass door panels up to 19mm. Built with premium SS304 covers.
Sidelite Transom Top Patch
Top transom-mounted clamp. Fitted with structural decorative blank plates.
Transom Stop Patch
Integrated stop buffer / limit plate. Controls physical opening limits to prevent panel impact.
Transom Stop Connector
Bridges transom panel seams while introducing dual stop elements for double doors.
Adjustable Bottom Patch
Allows horizontal tuning of 6mm and vertical tuning of 5mm post-installation.
Adjustable Top Patch
Equipped with 3D alignment capabilities to align axis centerlines with structural framing.
Adjustable Overpanel Patch
Multi-point adjustable connector. Resolves installation gaps for structural safety.
3. Security Lock Clamps, Keepers & Cylinders
Center / Floor Lock
Secures bottom center glass edge. Available with solid oval deadbolts or square floor bolt shapes.
Center Latch Keepers
Inline keeper box matching adjacent glass panels or door frames. Built with SS304 casing.
Lock Clamp (Round Bolt)
Central clamp featuring a dynamic round steel deadbolt. Prevents lateral entry play.
Lock Clamp with Lever Handle
Premium locking assembly outfitted with ergonomic handles for convenient egress control.
American Standard Lock Carrier
SS304 precision-cast lock carrier compatible with framed doors, glass rails, and UN1.150-32 specs.
Solid Brass Key Cylinder
American standard threaded brass cylinder. Customized barrel lengths available upon request.
Brass Thumbturn Cylinder
Interior-side thumbturn mechanism. Ensures simple egress without needing mechanical keys.
Stainless Strikes & Covers
Stainless steel dust strike plates and floor boxes to secure deadbolt entry slots cleanly.
4. Pivots, Closer Arms & Floor Springs
Hydraulic Floor Spring / Pivot
Variable speed closing mechanism. Supports maximum door weights of 100kg (FP5) and 150kg (FP6).
Adjustable Top Pivot Plate
Allows height offsets up to ±5mm via integrated adjusting bolt. SS304 finish covers.
Surface Mounted Top Pivot
Top surface bracket securing header pivots directly to concrete or wooden door headers.
Adjustable Walking Beam Pivot
Zinc alloy articulating pivot arm containing solid rolling bearings. SS304 backplate covers.
Short Floor Closer Arm
Carbon steel arm compatible with multiple floor closers. Zinc plating finish options.
Long Floor Closer Arm
Carbon steel arm (extended length 235mm) designed to maximize physical leverage for heavy doors.
Technical Parameter Sheet
Cross-reference table showing dimensions, weight ratings, compatibility scopes, and accessories for the ZHUTAO Series A.
Rigorous Structural Assurance
The ZHUTAO Series A is engineered and manufactured to deliver persistent, rattle-free centering and security locks in heavy traffic entries.
Global Wholesale Parameters
Standard batch orders complete in 15-25 business days. Bespoke finishes or customized castings require additional mold-tuning cycles.
MOQ starting at 200 units per model category for custom logo laser-etching on S.S. patch covers and tailored boxing.
5-Year structural integrity warranty covering casting shear vectors, pivots, and premium surface finishes in normal usage.
